Front brake arm kit incl. brake cam and bushing/suspension -BGM ORIGINAL- Vespa PX (1984-1998), T5 125cc, PK, Motovespa TX200

Description

Complete revision set brake arm/brake cam for the front brake anchor plate

suitable for Vespa PX Lusso, T5, Vespa PK XL/XL2/FL/HP, Motovespa TX200/T5 SportSet

consisting of

:

• Mounting for the brake cam

• Brake cam

• Brake arm

• Small parts

With the introduction of the so-called Lusso models (Italy: Arcobaleno, Spain: Iris, UK: EFL), Piaggio has significantly improved the braking performance of the front brake. The floating brake cam plays a key role in this. This can always center itself with the help of the bushing/mounting shown here and the brake shoes always lie cleanly on the radius of the drum. This technology also compensates for brake shoe wear.

The mount is fixed to the brake anchor plate with an M6 screw. Its contact pressure on the mount is limited by a bushing. This ensures that the mount always remains movable.

This component is no longer produced by Piaggio
